MCOR 1230 (mCoat IM HT) is an ultra-high performance silicone-epoxy hybrid coating system which combines the advantages of both technologies. Formulated with bifunctional curing agents, the dual nature of its reactivity allows the system to bind chemically to both inorganic materials and organic polymers thus creating ultra-high crosslink density, specifically engineered to resist up to 230 °C (446 °F) immersive or pressurized high temperatures, and protect against aggressive, concentrate chemicals. In addition, MCOR incorporates titanium and phyllosilicates (sheet-like arrangement of atoms) to enhance temperature tolerances, abrasion resistance, chemical resistance, and hold long-term high gloss retention even under intense U.V. environments.

mCoat IM HT is a truly unique, new generation coating for immersion grade high temperature applications. With its ultrahigh crosslink density and plated matrix, these bound sheet arrangements provide reinforcement to the material with features that are chemically inert, dielectric/insulating, flexible, reflective, refractive, and resilient.

The mCoat IM HT is an ultra-high solids coating, simple to use, forgiving, and cures to a hardened finish for barrier protection in industrial high temperature, wear and chemical areas. Often sought for internal component coatings of high velocity fluid flow areas, steam areas, or for corrosive storage and transport systems; the coating also is utilized for troughs, vessels, and other structures where harsh attack from heat, abrasion and corrosion often occur. Formulated with rust/corrosion inhibitors and incredible U.V. resistance, the system is also popular for exterior surface protection.

Category:

mCoat IM HT will:

  • Resist temperature exposure up to 230 °C (446 °F)
  • Provide excellent chemical and abrasion resistance
  • Have long-lasting sheen, protection and UV stability

mCoat IM HT is:

A UNIQUE, “NEXT GENERATION” HIGH TEMPERATURE COATING + LINER

mCoat IM HT is a truly unique, next generation coating for immersion grade high temperature applications. Many high temperature grade coatings in the market are formulated as thin films with inherent rigidity, making them either difficult or impossible to use as a sealed coating or liner. MCOR scientists however, were able to design the mCoat IM HT with a reinforced semi-flexible film and medium-to-high build dry film thickness, thus providing immersion grade sealing capability for enhanced corrosion resistance and barrier coating needs without sacrificing heat tolerances. With its ultrahigh crosslink density and plated matrix, these bound sheet arrangements provide reinforcement to the material with features that are chemically inert, dielectric/insulating, flexible, reflective, refractive, and resilient.

BUILT FOR OPTIMIZED VERSATILITY

mCoat IM HT is an ultra-high solids coating, simple to use, forgiving, and cures to a hardened finish for barrier protection in industrial high temperature, wear and chemical areas. Often sought for internal component coatings of high velocity fluid flow areas, steam areas, or for corrosive storage and transport systems; the coating also is utilized for troughs, vessels, and other structures where harsh attack from heat, abrasion, chemicals and corrosion often occur. Formulated with rust/corrosion inhibitors and incredible U.V. resistance, the system is also popular for industrial-grade exterior surface protection.

Downloads

Technical Data Sheet

Applications

  • Heated fluid systems and pumps
  • Heat exchangers and regenerators
  • Separators/centrifuges/knock-out drums
  • Scrubbers and absorbers
  • Heaters, boilers and return tanks
  • Steam and condensation systems
  • Economizers and preheaters
  • Distillation units
  • Isolation spools

Features

  • Immersion-grade
  • High heat tolerance
  • High abrasion resistance
  • High level chemical protection
  • Thermal cycle performance
  • Simple to apply
  • Ultra-high solids (low VOCs)
  • Surface tolerance
  • Incredible UV resistance
  • Long term gloss retention
  • Built-in rust/corrosion inhibitors

Kit Offerings

  • 11 Kilo Unit (1 x 11kg, DGY)
  • 1 x 9.53kg, MCOR 1230 Part-A, Dark Grey
  • 1 x 1.47kg, MCOR 1230 Part-B

The volume capacity of a 1 kg of mixed mCoat IM HT is 936 cm3 (57 cu.in.).

mCoat IM HT is designed to be applied as a two-coat system. Applied at 200 microns (8 mils) minimum to 350 microns (14 mils) maximum, per coat.

mCoat IM HT is a near 100% solid coating that will not shrink. 3.74 m2/kg. at 250 µ DFT (40 ft2/kg. at 10 mils DFT). Actual coverage will depend on surface conditions, irregularities, and surface profile.

Important: Do not exceed 350 microns (14 mils) per coat. If applying multiple coats, recoat window schedules must be observed.
